Verfügbarkeitsstatus: | |
---|---|
| |
Bewertungsschub (n) | 150 | Fixed End Montageslochdurchmesser (mm ) | φ4 |
Max -Schub (n) | 500 | Moving End Montageslochdurchmesser (mm ) | φ4 |
Lineare Geschwindigkeit (mm/s) bewertet | 50 | Nennspannung (VDC) | 48 |
Maximale lineare Geschwindigkeit (mm/s) | 100 | Nennleistung bewertet (W) | 23.58 |
Schlaganfall (MM) | 45 | Nennmoment (NM) | 0.075 |
Encodertyp | Multiturn absoluter Magnetkodierer | Sofortiger Max Drehmoment (NM) | 0.23 |
Encoder -Auflösung | 17-Bit | Bewertungsstrom (a) | 3 |
Gewicht (kg) | / | Instantane Maximalstrom (a) | 9 |
Schraubtyp | T-Typ-Bleischraube | Nenngeschwindigkeit (Drehzahl) | 3000 |
Axialspiel (MM) | / | Maximale Geschwindigkeit (Drehzahl) | 6000 |
Axial Montageabstand (MM) | 116 | Rotorstastpaare | 7 |
Bewertungsschub (n) | 150 | Fixed End Montageslochdurchmesser (mm ) | φ4 |
Max -Schub (n) | 500 | Moving End Montageslochdurchmesser (mm ) | φ4 |
Lineare Geschwindigkeit (mm/s) bewertet | 50 | Nennspannung (VDC) | 48 |
Maximale lineare Geschwindigkeit (mm/s) | 100 | Nennleistung bewertet (W) | 23.58 |
Schlaganfall (MM) | 45 | Nennmoment (NM) | 0.075 |
Encodertyp | Multiturn absoluter Magnetkodierer | Sofortiger Max Drehmoment (NM) | 0.23 |
Encoder -Auflösung | 17-Bit | Bewertungsstrom (a) | 3 |
Gewicht (kg) | / | Instantane Maximalstrom (a) | 9 |
Schraubtyp | T-Typ-Bleischraube | Nenngeschwindigkeit (Drehzahl) | 3000 |
Axialspiel (MM) | / | Maximale Geschwindigkeit (Drehzahl) | 6000 |
Axial Montageabstand (MM) | 116 | Rotorstastpaare | 7 |
