Verfügbarkeitsstatus: | |
---|---|
| |
Bewertungsschub (n) | 650 | Fixed End Montageslochdurchmesser (mm ) | φ8 |
Max -Schub (n) | 4000 | Moving End Montageslochdurchmesser (mm ) | φ8 |
Lineare Geschwindigkeit (mm/s) bewertet | 225 | Nennspannung (VDC) | 48 |
Maximale lineare Geschwindigkeit (mm/s) | 330 | Nennleistung bewertet (W) | 220 |
Schlaganfall (MM) | 65 | Nennmoment (NM) | 0.7 |
Encodertyp | Multiturn absoluter Magnetkodierer | Sofortiger Max Drehmoment (NM) | 4.2 |
Encoder -Auflösung | 17-Bit | Bewertungsstrom (a) | 8.2 |
Gewicht (kg) | / | Instantane Maximalstrom (a) | 52 |
Schraubtyp | Planetenrollenschraube | Nenngeschwindigkeit (Drehzahl) | 3000 |
Axialspiel (MM) | 0.02 | Maximale Geschwindigkeit (Drehzahl) | 4500 |
Axial Montageabstand (MM) | 250 | Rotorstastpaare | 5 |
